5-1-1 Day Programmable Thermostat

Multi Stage
2 Heat, 2 Cool
5-1-1 Day Programmable
Easy menu driven programming
Intuitive wake, leave, return, sleep programming icons
4.5 sq. inch large LCD display with white backlight
Easy access battery compartment
Electric or Gas configurable
Separate B & O terminals
Separate heating and cooling swing (cycle rate)
Air filter change indicator (selectable on or off)
Low battery indicator
Room temperature calibration adjustment
5 minute compressor delay protection (selectable on or off)
Display options: Fahrenheit or Celsius temperature display, 12 or 24 hour clock
Easy wire coded terminal blocks
Terminal Designations: RH, RC, G, Y, Y2, C, O, B, W, W2
Universal sub-base
Mounts on wall or junction box
Battery or 24VAC power
Load rating: 1 Amp per terminal, 1.5 amp maximum all terminals combined
Temperature display range: 41°F to 95°F
Temperature control range: 44°F to 90°F

Package include:
H715 Thermostat
(Jumper wire connected)
Two screws and anchors
Operation Manual
Installation Manual
Cable Label

H715 is low voltage multi stage thermostat, A simple, easy to use 1-week(5-1-1 Day) programmable thermostat. You set it up to adjust the temperature when you are away or asleep-times when you don't necessarily need to heat or cool your home to optimum comfort-and your HVAC equipment runs less. Plus, your heating or cooling comes back to the comfort level you desire before you come home or wake up, and have 5-year warranty.
Buyers should thoroughly examine the installation and wiring instructions depicted in the images before buying. It is recommended to exercise caution if you lack experience in installation to avoid potential problems like product malfunction or incompatibility due to incorrect purchases. (If you have any questions, please feel free to contact us).
【Compatible Systems】Single-Stage and 2-Stage Gas/Oil/Electric Furnace (Heat only) , Boiler Radiant (Heat only), Furnace Forced-Air (Heat Only), Gas Fireplace (24 Volts) and 2-Stage Cooling.
【Incompatible Systems】Does Not Work: HVAC Central Air Conditioner Heat Pump System (with Auxiliary or w/o Auxiliary Heating); Dual Fuel/Hybrid Multistage Heating; Mini Split Systems, RV; Convectors; Radiant Ceiling Heat; Electric Baseboard Heat ( 120-240 Volts)
H715 5-1-1 day programmable thermostat for home conventional single or multistage systems up to 2 Heat/ 2 Cool. (Separate programs for the weekdays and weekends with 4 program periods per day including wake, leave, return and sleep).
Accurate temperature control of +/-1-Degree F for consistent comfort, Room temperature display range: 41°F to 95°F, Temperature control range: 44°F to 90°F.
Separate Heating and Cooling Swing (Cycle Rate). Which will Either Prolong or Shorten the Temperature Open Time. Make Comfortable Temperatures to Teduce Energy Usage, Savings on Annual Heating and Cooling Costs.
Support room temperature error display calibration adjustment and 5 minute compressor delay protection (Selectable on or off), with air filter change reminder and low battery indicator available (Tip: Please replace the accessories in advance).
Support Dual Powered 24VAC Power or 2 AAA Batteries. No Common Wire (c-wire) Rrequired on Most 24V Conventional Single-Stage Systems. ( Notice: Only Required on Heat Only and Cool Only Systems ).
3 Inches Display with white Backlight, Easy-to See and Read. Large, Clear Backlit Digital Display, Very Suitable for Middle-Aged and Elderly People.
After-sales Service: If you have any problem, please feel free to contact us, we will repley you in 24 hours. the products come with 30 days free return, 2-year Worry-Free Warranty.
